19 Pin Circular Push Pull Connector S1031A Series PPS Insulator Solder Type

Type : Waterproof plug

Application : Audio & Video

Gender : male and female

Certificate : ISO9001/CE/ROHS/SGS

IP Rating : IP68

shell style /model : Straight plug and fixed socket

Housing Material : black /natural chrmoe-plated brass

contact no : 10,12,15,19pins

Insulator : PPS

Contact type : solder type

Cable accembled or not : YES

Max. mating : 5000

MOQ : No MOQ limit

Port : SHENZHEN

Certification : CE ROHS2.0 REACH ISO:9001-2015

Place of Origin : Guangdong, China

Brand Name : RAYMO

Model Number : RM-S-AF1S-P19JS-052/DBPU-AF1S-P19KS

Supply Ability : 5000 Piece/Pieces per Week

Packaging Details : Plastic bag and carton

MOQ : >=1 Pieces

Price : Negotiable

Contact Now

Prct Description
IP68 Waterproof electrical metal circuar push pull connector S1031A series 19pin cable plugs
Technical Characteristics
Endurance(shell)
5000 mating cycles
Humidity
up to 95% at 60° C/140F
Temperature Range
- 65° C, +200° C
Resistance to vibrations
15 g [10 Hz - 2000 Hz]
Shock Resistance
100 g [ 6 ms]
Salt spray corrosion test
>96 hr
Climatical Category
50/175/21
Shielding (min)
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating
IP 68
Certifications
ISO9001/CE/ROSH/SGS
RM-S-AF1S-P19JS-052/RM-DBPU-AF1S-P19KS
Shell model
S straight plug / DBPU socket
Shell size
1031 series/ AF
Gender
Male and female
Contact No.
10,12,15,19
MOQ
no limit
Delivery
3-5 working days
RM-F Series Main features

1. Security of the push-pull self-latching system;
2. Multipole types with 2 to 19 pins contacts;
3. Solder or PCB contacts(straight or elbow);
4. 360°screening for full EMC shielding;
5. High-density installation for space-saving;
6. Multiple key options to avoid cross mating of similar connectors;
7. Made of bronze beryllium and have a gold-plated surface;
8. Have brass out shells which have a chrome nickel-plated surface.

Applications

Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor, Sensor Systems Instrumentation, Analysis Application.

Prcts photos

19 Pin Circular Push Pull Connector S1031A Series PPS Insulator Solder Type

Certificates
19 Pin Circular Push Pull Connector S1031A Series PPS Insulator Solder Type
Our Company
19 Pin Circular Push Pull Connector S1031A Series PPS Insulator Solder Type

Raymo Connectors Co., Ltd. is located in Shenzhen China. We are a professional manufacturer of connectors and cable assembly. And we are seting design, development, manufacturing as a professional manufacturer.We focus on a series of fashion accessories, a wide range of diversity, reasonable price and on-time delivery.

As manufacturer, we focusing on manufacturing connectors and cable assemblies serive more than 150 countries since 2010. Raymo Connectors is committed to working closely with its customers to equip their application with the most appropriate connector and cable system. Our prct range comprises over 3,000 standard items and we are always prepared to develop customized solutions for specific requests.
Our Service

1. Main prcts: connectors and cable assembly
2. High quality, competitive price, fast delivery (5-7 working days)
3. Main market: North America, Europe, Asia, North Africa, Oceania
4. OEM Manufacturing welcome: Prct, Package...
5. No MOQ limited
6. Free sample available.
7. We will reply you for your inquiry in 24 hours.
8. after sending, we will track the prcts for you once every two days, until you get the prcts. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.

FAQ

1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular push pull connectors and cable assembly since 2010.
Our factory is SGS audited manufacturer and served global customers for more than 5 years.

2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.

3. Free sample:
Raymo: Available. Any needs, please contact us.

4. What about the delivery time?
Raymo: sample for 1-2 working days, mass prction for 5-10 working days.

5.What is your payment terms?
Raymo: 100% T/T deposit when customer place order.

6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
